CT-8000 Battery Testing System
CT-8002S-5V100mA-EIS
Highly accurate 4-range tester, master of detail realism. Current ranges of 5mA~300mA, 30mA~3A, 60mA~6A, 150mA~15A can be selected to realize the controllable accuracy of small current in small range.
High precision & fast sampling
Voltage range covers -5V~5V, maximum current 100mA with automatic switching among multiple current ranges. High-precision voltage and current measurement combined with high-speed sampling accurately captures all details.
Fast current response & switching
Microsecond-level current response time. Adopting bipolar linear circuits, the current crosses zero smoothly with no switching delay between charge and discharge.
Fast current response & switching
Microsecond-level current response time. Adopting bipolar linear circuits, the current crosses zero smoothly with no switching delay between charge and discharge.
Multi-scan rate CV testing
Dual-channel simultaneous CV testing. The test sequences for charge-discharge and CV are issued uniformly without battery repositioning, greatly improving test efficiency.
| Model | CT-8002S-5V100mA-EIS |
| Resolution | AD：24bit；DA：16bit |
| Voltage | |
| Output Range | -5V-5V |
| Min discharge voltage | -5V |
| Accuracy | ± 0.01% of F.S. |
| Stability | 0.02% of F.S. |
| Current | |
| Output Range | Range1: 0.1mA |
| Range2: 1mA | |
| Range3: 5mA | |
| Range4: 10mA | |
| Range5: 50mA | |
| Range6: 100mA | |
| Accuracy | ± 0.01% of F.S. |
| Minimum output current | 0.02μA |
| CV cut-off current | Range1: 0.1mA |
| Range2: 1mA | |
| Range3: 5mA | |
| Range4: 10mA | |
| Range5: 50mA | |
| Range6: 0.1mA | |
| Stability | 0.02% of F.S. |
| Power | |
| Single channel output power | 0.5W |
| Accuracy | ±0.02% of F.S. |
| Stability | 0.04% of F.S. |
